CE Certification Heavy Duty Triple Stacker Four Post Parking Lift Manufacturers, Products

The Triple Level Four Post Parking Lift redefines space efficiency, stacking three to four vehicles vertically for high-density residential and commercial use. Each platform supports up to 3,000kg on commercial-grade construction built for continuous operation. Optional shared columns let units connect in rows, freestanding or integrated, indoors or out, finished in powder coating or hot-dip galvanizing. Independent electric-hydraulic power packs with key-switch control ensure smooth, stable lifts at every level, while automatic mechanical locks, hydraulic overload protection, and anti-explosion valves safeguard every stage.

Send Inquiry

Product Description

The CQSL-3 and CQSL-4 multiply the capacity of a single parking bay by three or four times, with each platform rated to carry up to 3,000kg across sedans, SUVs, and light trucks. Heavy-duty construction and indoor-outdoor compatibility make them a practical, high-density solution for car dealerships, vehicle storage facilities, airport long-stay operations, and hotel valet parking where space efficiency is non-negotiable.

Product Specifications

Model No.	CQSL-3	CQSL-4
Lifting Capacity Per Platform	3000 kg
Lifting Height	2150 mm
Usable Platform Width	2405 mm
Overall Height	7503 mm	10093 mm
Overall Length	4947 mm
Overall Width	2945 mm
Power Supply / Motor Capacity	380V, 50Hz / 60Hz, 3Ph, 7.5Kw
Operation Mode	Key Switch + Button
Lock Release	Manual Lock Release Handle
Drive Mode	Hydraulic Drive + Steel Wire Rope

Product Features

Certified to EC Machinery Directive 2006/42/EC with full CE compliance
Each platform rated to a 3,000kg lifting capacity for heavy-duty vehicle loads
Available in 3-level or 4-level configurations with shared-column multi-unit connectivity
Commercial-grade materials and structural components throughout for extended service life
Deployable as individual standalone units or linked in continuous row installations
Electric key switch restricts operation to authorized personnel only
Powered by dedicated independent electric-hydraulic units for consistent lift performance
Hydraulic overload protection system prevents damage under excess load conditions
Automatic mechanical safety locks engage at every height position across all columns
Anti-explosion valves on each hydraulic cylinder guard against sudden pressure loss
Powder-coat finish for interior environments; hot-dip galvanizing for outdoor exposure

Product Applications

■ Car Dealerships

Efficiently store and display multiple vehicles, improving accessibility, maximizing showroom or service area space, and supporting short-term or long-term vehicle storage.

■ Automotive Warehouses

Organize large volumes of vehicles in commercial storage facilities, optimizing space while ensuring safe and convenient access for inventory management.

■ Vehicle Storage Providers

Offer secure short-term or long-term parking solutions for sedans, SUVs, and light vehicles, ideal for storage businesses and fleet management.

■ Residential & Commercial Parking

Increase parking capacity in apartments, offices, and commercial parking lots with a compact, reliable, and multi-level stacker system.

■ Car Collection & Enthusiast

Safely store multiple vehicles in limited space, providing easy access, protection, and organized parking for car collectors or enthusiasts.

Why Choose Triple & Quad Car Stacker – 3 & 4 Level Parking Lift?

Maximize Parking Capacity

Three- or four-level design allows multiple vehicles to be stored vertically, efficiently increasing parking space without expanding the ground footprint.

Flexible Configuration

Shared column structure enables multiple connected units; can be installed as standalone or in continuous rows for commercial and dealership applications.

Reliable Operation

Independent power units ensure stable, quiet, and energy-efficient lifting performance for safe daily use.

Commercial-Grade Construction

Heavy-duty steel frame, automatic mechanical safety locks, and anti-explosion hydraulic valves provide long-term stability and reliable operation.

Enhanced Safety Features

Equipped with hydraulic overload protection, multi-level mechanical anti-fall locks, and electric key switch control to ensure secure and reliable operation.

Wide Vehicle Compatibility

Supports sedans, SUVs, pickups, and light commercial vehicles, making it suitable for dealerships, warehouses, and storage providers.

Versatile Application Range

Ideal for automotive dealerships, vehicle storage facilities, commercial garages, and long-term or short-term car storage projects.

Compliance & Easy Integration

CE certified and designed to meet local building codes and clearance requirements; pre-welded components allow straightforward on-site installation.

Frequently Asked Questions

Q How does the Triple & Quad Car Stacker work?

The system uses a multi-level electric-hydraulic lift to raise platforms vertically, allowing vehicles to be stacked safely on 3 or 4 levels. Each platform operates with dual-cylinder power units for smooth, stable, and quiet lifting.

Q How many cars can it park?

Each unit can accommodate 3 or 4 vehicles depending on the model (Triple or Quad), maximizing vertical parking space without expanding the ground footprint.

Q Is the system safe to operate?

Yes. It features mechanical anti-fall locks on every height, hydraulic overload protection, anti-explosion valves, and electric key switch control to ensure safe and reliable operation.

Q What types of vehicles can be parked?

Suitable for sedans, SUVs, pickups, and light commercial vehicles, depending on platform dimensions and lifting capacity (up to 3000kg per platform).

Q Where can this system be installed?

Ideal for automotive dealerships, commercial garages, vehicle storage facilities, and long-term or short-term car storage projects.

Q Can the system be customized?

Yes. Platform size, number of levels, lifting height, load capacity, surface treatment, and layout (standalone or connected units) can be tailored to project requirements.
